Posts:

  • Post Material: 6063 T-6 Aluminum

  • Post Height: Varies depending on number of panels

  • Post Weight: 3.025lbs per ft.

  • Post Depth: 3.94” (10cm)

  • Post Width: 2.36” (6cm)

  • Center Post Width (Double Channel): 5.12” (13cm)

  • Center Post Weight: 6.05lbs per ft.

  • Sealing Material: Rubber EPDM

Panels:

  • Panel Material: 6063 T-6 Aluminum

  • Panel Width: Varies Depending on Opening Size

  • Individual Panel Height: 7.87” (20cm)

  • Panel Weight: 2.016lbs per ft.

  • Panel Depth: 1.58” (40mm)

  • Panel Wall Thickness: 0.0787” (2mm)

  • Sealing Strip Material: Rubber EPDM

  • Tallest Protection Height: 6.6ft (10 panels)
